GGU-SLAB

GGU-Slab GGU-SLAB

Analysis of elastically supported slabs based on the modulus of subgrade reaction and constrained modulus methods using the finite-element method.


Capabilities:

  • Powerful mesh generator (for generating circular, annular and elliptical slabs)
  • Subgrade modulus profile can be varied as required
  • Finite-element mesh coordinates can be imported from a table via the Windows clipboard
  • Any type of slab boundary including holes
  • Any slab thickness can be defined within the foundation
  • Beam elements for modelling foundation beams or walls
  • Single springs, perpendicular to slab, e.g. for modelling piles
  • Definition of linearly variable subgrade reaction moduli within an element
  • Constrained modulus distribution can be defined by stratigraphic profiles and an interpolation mesh
  • Modeling of any soil stratification
  • Soil properties can be selected from an expandable database of common soils
  • Export and import of constrained modulus profiles or an interpolation mesh for the constrained modulus to and from the computer program GGU-SETTLE
  • Consideration of vibro-displacement compaction after Priebe
  • Consideration of kappa correction coefficients (DIN 4019) possible
  • Excavation unloading can be taken into account. 
  • Limiting depth analysis for constrained modulus method using p % of overburden stress, a multiple of foundation width or a fixed value
  • Visualization of internal forces: moment, shear force, displacements (including determination of torsional stiffness for multi-layered systems) and pressure in the foundation base
  • Differing concrete cover thickness for the upper and lower slab surface possible
  • Slab reinforcement according to EC 2
  • Numerous options for visualizing the evaluation results, e.g. as contour lines, 3D graphics or in sections
  • Computation and visualization of settlement depressions
  • User-designed output sheet
  • Print or copy screen sections, e.g. for transfer to a word processor
  • Integrated Mini-CAD system for additional annotation of graphics
