GGU-FOOTING

GGU-Footing GGU-FOOTING

Analysis of spread foundations: verification of the bearing capacity according to DIN 4017, highly eccentric loads, limitation of misalignment, sliding. Aditionally analysis of settlements according to DIN 4019.


Capabilities:

  • Choice of analysis using either partial safety factors according to EC 7, DIN 1054:2010, Austrian Standard ÖNORM EN 1997-1 or global safety factors (DIN 1054 old)
  • System input and visualization using absolute heights
  • Soil properties can be selected from an expandable database of common soils
  • Consideration of vibro-displacement compaction after Priebe

Bearing capacity:

  • Bearing capacity equations to DIN 4017 (2006/old), Terzaghi, Meyerhoff, Hansen or Vesic can be selected
  • Analysis of multiple footings of a single type (variation of footing width)
  • Analysis of single rectangular footings or single circular/annular footings
  • Consideration of multiple soil layers and determination of mean governing soil properties using a logarithmic spiral
  • Verification of the 5° condition, and correction through iterative reduction of shear friction angles that are above the current mean value
  • Consideration of berms an slopes
  • Consideration of the footing’s base inclination
  • Consideration of pre-loading for the analysis of settlements
  • Punching analysis for flexible and rigid footings (DIN 4017)
  • Optimization of the foundation’s dimensions possible
  • Creation of a footing analysis diagram with the bearing resistance design value or allowable soil pressure and a set of curves with resulting settlements as well as modulus of subgrade reaction contour lines
  • Presentation of analysis results as tables
  • Plan view of the footing (single footings) with forces, the core dimensions, settlements etc.
  • Presentation of the logarithmic spiral
  • Interface to the computer program GGU-STABILITY for the verification of the global stability

Sliding, highly eccentric loads, limitation of misalignment:

  • Sliding safety analysis adopting user-defined friction angles possible
  • Computation of eccentricities for dead loads (permanent) and live loads (changable)
  • Verification of highly eccentric loads (EQU) and limitation of misalignment

Settlements:

  • Settlement analysis at the characteristic points (DIN 4019) 
  • Consideration of pre-loading possible
  • Consideration of the limiting depth
  • Determination of torsional stiffnesses for single footings
  • Consideration of kappa correction coefficients (DIN 4019:1979)

Evaluation:

  • Presentation of system geometry
  • Presentation of stress distribution
  • Presentation of soil properties, general information on your analysis data, adopted standard, program name and version displayed in legends
  • Freely definable positioning and sizing of graphical elements and legends
  • Print or copy screen sections, e.g. for transfer to a word processor
  • Integrated Mini-CAD system for additional annotation of graphics
